Apatite, Phosphorite and Phosphate Rock



What is Apatite?



Apatite is the name of a group of phosphate minerals with similar chemical compositions and physical properties. They are an important constituent of phosphorite, a rock mined for its phosphorus content and used to make fertilizers, acids, and chemical. Apatite has a relatively consistent hardness and serves as the index mineral for a hardness of five in the Mohs Hardness Scale. Specimens with excellent clarity and color are sometimes cut as faceted gemstones. Those with good color and translucence are cut as cabochons.


The Apatite Mineral Group



Minerals in the apatite group are all calcium phosphates with the same crystalline structure. The generalized chemical composition of apatite is Ca5(PO4)3(OH,F,Cl). This formula represents an admixture of the three important minerals of the apatite group: hydroxylapatite, fluorapatite and chlorapatite.

These minerals are distinguished by their OH-, F- and Cl- content. Hydroxylapatite contains a hydroxyl (OH) and has a chemical composition of Ca5(PO4)3(OH). Fluorapatite contains fluorine (F) and has a chemical composition of Ca5(PO4)3(F). Chlorapatite contains chlorine (Cl) and has a chemical composition of Ca5(PO4)3(Cl).

Some mineralogists believe that francolite, a carbonate-rich apatite found as a diagenetic mineral replacing the bone tissue of many fossils is also a member of the apatite group. It has a chemical composition of Ca5(PO4,CO3)3(F,O).

Collophane is a name used for the massive phosphatic material of phosphate rock and fossil bone. It is a mixture of cryptocrystalline apatite minerals and amorphous calcium phosphates.


Physical Properties



Apatite is best known for its use as an index mineral with a hardness of 5 in the Mohs Hardness Scale. It is usually green in color, but can be yellow, brown, blue, purple, pink or colorless. These colors are often so vivid that apatite has frequently been cut as a gemstone. Apatite is a brittle material. It breaks by both fracture and cleavage but the cleavage is generally indistinct. Hexagonal apatite crystals are sometimes found in igneous and metamorphic rocks.


Physical Properties of Apatite

Chemical Classification Phosphate.
Color Green, brown, blue, yellow, violet, pink, colorless. Transparent specimens with excellent clarity and vivid color are used as gemstones.
Streak White.
Luster Vitreous to subresinous.
Diaphaneity Transparent to translucent.
Cleavage Poor to indistinct.
Mohs Hardness 5
Specific Gravity 3.1 to 3.3
Diagnostic Properties Color, crystal form, and hardness. Brittle, often highly fractured. Can be scratched with a steel knife blade.
Chemical Composition A group of calcium phosphates.
    Fluorapatite: Ca5(PO4)3F
    Hydroxylapatite: Ca5(PO4)3(OH)
  Chlorapatite: Ca5(PO4)3Cl
    Carbonate-rich apatite/francolite:
      Ca5(PO4,CO3)3(F,O)
Crystal System Hexagonal.
Uses Fertilizer, phosphoric acid, hydrofluoric acid, gemstones, ore of rare earth elements, pigments, gemstone. Serves as a hardness of 5 on the Mohs Hardness Scale.


Geologic Occurrence



Apatite forms under a wide variety of conditions and is found in igneous, metamorphic and sedimentary rocks. The most important deposits of apatite are in sedimentary rocks formed in marine and lacustrine environments. There, phosphatic organic debris such as bones, teeth, scales and fecal material, accumulated and was mineralized during diagenesis. Some of these deposits contain enough phosphorus that they can be mined and used to produce fertilizers and chemical products.

Apatite occasionally occurs as well-formed hexagonal crystals in hydrothermal veins and pegmatite pockets. These crystals often have a very high clarity and a vivid color and have been cut into gems for collectors. Mineral collectors also enjoy these well-formed apatite crystals and the prices paid for them often exceeds their value as gem rough.


Phosphate Rock and Phosphorite



Phosphate rock and phosphorite are names used for sedimentary rocks that contain at least 15% to 20% phosphate on the basis of weight. The phosphorous content in these rocks is mainly derived from the presence of apatite minerals. Determining which apatite group minerals are contained in the rock can not be determined without laboratory testing because their particle sizes are so small.

Most phosphate rock has a non-detrital origin similar to limestone. Some of the phosphate is deposited by precipitation from solution; some is the remains and waste products of organisms; and, some is deposited by groundwater during diagenesis.

Like limestone, phosphate rock is deposited in sedimentary basins where the influx of detrital material is relatively low. That allows the phosphate to accumulate with very little dilution from other materials. Where the dilution rate is high phosphatic shales, mudstones, limestones and sandstones will form instead of phosphate rock.


Uses of Apatite as Phosphate Rock



Most of the phosphate rock mined throughout the world is used to produce phosphate fertilizer. It is also used to produce animal feed supplements, phosphoric acid, elemental phosphorous, and phosphate compounds for the chemical industry.

China is the largest producer of phosphate rock, producing approximately 100 million tons in 2014. The United States, Russia, Morocco and Western Sahara are also major phosphate producers. Over 75% of the world's reserves of phosphate rock are located in Morocco and Western Sahara.

Phosphate rock is the only material that can be used to produce enough fertilizer to satisfy world demand. Without it farmers would not be able to produce enough food to feed the world's population. It is surprising that one type of rock, that most people know nothing about, is so important to keeping the world fed and alive.


Gemology



Transparent specimens of apatite with vivid green, blue yellow or pink color and excellent clarity are often cut into faceted gemstones. Some stones are heat treated to improve their color.

Attractive translucent stones of excellent color are cut en cabochon. Rarely, translucent apatite contains a fine silk of parallel rutile crystals. When cut en cabochon with the silk oriented parallel to the bottom of the stone, these specimens will often exhibit a chatoyance known as "cat's eye".

As a gemstone, apatite is more popular with gem collectors than it is with jewelry buyers. The mineral has a Mohs hardness of 5, breaks with parting, and is very brittle. These characteristics make it too fragile for use in most types of jewelry.

Last modified: July, 2015

Contributor:



Find it on Geology.com




More from Geology.com


Plate Tectonics
Plate Tectonics: Articles and maps about plate tectonics and the interior of Earth.
Peridotite
Peridotite is a chromite host rock, a source of diamonds and a possible carbon dioxide sink.
hunting meteorites in Antarctica
The Richest Meteorite Field - More meteorites found here than anywhere else on Earth.
Gemstones
Gemstones: Fantastic images and articles about colored stones and diamonds.
Yosemite Rock Fall Photos
Yosemite Rock Fall Photos: A photo sequence of a rockfall and debris avalanche by Herb Dunn.
Crushed Stone
Crushed Stone - About four tons per person is used each year in the United States.
Where Do Bears Live
Where Do Bears Live in North America? Geographic range of grizzly, polar and black bears.
hurricane names
How Are Hurricanes Named? Names are assigned as tropical storms are discovered.


Apatite crystals
Apatite Crystals: A scatter of small greenish-yellow apatite crystals from Cerro del Mercado, Durango Mexico. These hexagonal crystals are small, mostly about 8 millimeters in length. Apatite crystals of this clarity are not often found in large sizes. Image copyright by geology.com.




Apatite from Canada
Faceted Apatite: Five faceted stones from Madagascar in various colors. Clockwise from left: a green 8 x 6.2 millimeter oval of 1.23 carats; a yellow 8 x 6.3 millimeter oval of 1.37 carats; a bluish green 8.1 x 6.2 millimeter oval of 1.38 carats; a blue 7.1 x 5 millimeter oval of 0.91 carats (heat treated); and, a bluish green 7.1 x 5.2 millimeter oval of 1.05 carats (heat treated).


Apatite crystal
Cat's Eye Apatite: Two nice cabochons with a chatoyance produced by a fine silk of rutile needles. The stone on the left is a yellow 7 x 5.9 millimeter oval of 1.82 carats cut from apatite mined in Kenya. The stone on the right is a greenish golden (heat treated) 9.3 x 6.9 millimeter oval of 2.77 carats cut from apatite mined in Kenya.


phosphate rock
Phosphate Rock from the Upper Zhujiaqing Formation of the Yunnan Province of Southwestern China with a fossiliferous peloidal texture. Photograph by James St. John, used here under a Creative Commons License.


phosphate rock
Phosphate Rock from the Simplot Mine, Phosphoria Formation of Southeastern Idaho with a peloidal texture. Photograph by James St. John, used here under a Creative Commons License.
